Kowa Optronics Co., Ltd., a subsidiary of the large Japanese company Kowa Company, Ltd., has been a leader in high-end optical equipment manufacturing since 1946. Their expertise spans various sectors, including healthcare, industrial applications, and energy conservation. This blog post delves into their extensive range of machine vision lenses, categorized by sensor size and specialized features.
Sensor Size and Resolution: Kowa's machine vision lenses cater to a wide variety of sensor sizes, from 1/3-inch to 2-inch formats, supporting resolutions ranging from megapixels to 50 megapixels. This broad selection ensures compatibility with diverse imaging systems, from compact solutions to high-resolution applications demanding exceptional clarity.
Key Lens Series and Features: The catalog showcases several lens series, each tailored to specific needs. Notable series include:
VM Series: These 2-inch, 50-megapixel lenses are designed for large image sizes (32mm) and high-resolution applications like 8K. A noteworthy feature is the innovative switch locking screw mechanism preventing thumb screws from falling off during use. Multiple mount adapters provide flexibility in system integration.
XC Series: The 4/3-inch, 20-megapixel XC lenses incorporate a C-mount design, maintain megapixel resolution across the entire image, and utilize high-precision aspherical lenses to minimize distortion. The floating mechanism system effectively mitigates optical aberrations.
FC24M Series: These 1.1-inch, 24-megapixel lenses are compact and high-resolution. Their floating mechanism system corrects aberrations, and the wide-band multi-coating minimizes ghosting and flare.
HC Series: The 1-inch megapixel HC lenses offer excellent corner brightness and low distortion, encompassing various focal lengths.
HC-V Series: Designed for high-vibration and shock environments, these ruggedized 1-inch megapixel lenses maintain optical performance using a unique mechanical design. The two-way reversible nut secures focus adjustment and eliminates screw loss issues.
JC10M Series: These 2/3-inch, 10-megapixel lenses are optimized for high-end inspection, boasting 200 lp/mm center resolution and low distortion. Aspherical lenses and a compact design improve system integration.
JC5M2, JC5MC Series: The JC5M2 and JC5MC Series are both 2/3-inch, 5-megapixel lenses with differing compact designs and features. The JC5MC lenses are particularly noteworthy for their small size and weight.
JCM-V, JCM-WP Series: These ruggedized 2/3-inch megapixel lenses are designed for high-vibration environments. The JCM-WP adds water and dust resistance, improving durability for demanding applications.
JC1MS Series: The JC1MS Series represents a wide range of 2/3-inch megapixel lenses, known for their excellent corner brightness and low distortion.
JC Series: The JC series represents a line of standard 2/3-inch lenses known for their cost-effectiveness and durability.
NCM/JCM Series: These wide-megapixel lenses provide a large angle of view with superior optical design to reduce distortion.
HC-VIS-SW Series: The 1-inch HC-VIS-SW series are 12-megapixel lenses with IR correction for use in visible and near-infrared (SWIR) ranges, and virtually no focus shift.
JC5M-IR Series: These 2/3-inch, 5-megapixel lenses feature IR-corrected design and a fast F-stop.
HC-SW Series: The HC-SW lenses utilize Kowa's special coating to maximize transmission for Near Infrared (NIR) and Short Wavelength Infrared (SWIR) applications.
Additional features: Many lens series feature low distortion, floating mechanisms for aberration correction, and wide-band multi-coating for improved transmission.
Accessories: Kowa also offers accessories such as close-up rings, filter holders, and mount adapters, further enhancing the versatility and customization options for their lenses. Detailed specifications, including image size, field of view, and distortion, are provided for each lens model.
Kowa Optronics presents a comprehensive range of machine vision lenses catering to various needs and applications. Their commitment to quality, innovation, and customization sets them apart, making them a reliable partner for diverse industrial imaging requirements. This catalog provides a detailed overview; however, for detailed information on specific lens selection for your individual application, further consultation may be required.
